The anti-static silicone wrist strap is developed based on the principle of "In Electrostatic Engineering" static electricity is transferred by the squeezing method between ions, and the electrostatic ions of the human body are pushed to the body design by the characteristics of electrostatic pushing from high potential ( Collecting area), through [charge induction principle], the front and back surfaces of the conductive plate will have "equal opposite charges"-skin effect, because the area has built-in ion exchanger< use="" its="" low="" free="" energy="" characteristic>="" ;,="" it="" can="" easily="" provide="" the="" same="" amount="" of="" charged="" electrostatic="" ions="" to="" be="" neutralized,="" so="" the="" effect="" of="" electrostatic="" discharge="" can="" be="" achieved.="" in="" addition,="" there="" is="" a="" screw="" on="" the="" outside="" of="" the="" machine="" to="" connect="" with="" the="" internal="" conductor="">
The human skin is in direct contact with the conductive material on the wrist strap. When the black anti-static wrist strap is grounded, the grounding system will quickly release the static electricity generated by the movement of the human body to effectively eliminate the static electricity, and achieve the end purpose of static discharge (static voltage balance) . The wrist strap is composed of a rubber band or Velcro ring, a metal ring, a rubber ring, a spring wire, and an alligator clip. It has the characteristics of fast dissipating electricity (S<0.1 second),="" durability="" (the="" spring="" wire="" can="" resist="" 30,000="" times="" of="" bending),="" safety="" (built-in="" 1mω="" current="" limiting="" resistor),="" and="" can="" be="" cleaned="">
Anti-static silicone wrist strapThe length of the spring wire can be customized according to customer requirements. Common specifications are 6 feet (1.83M), 8 feet (2.44M), 10 feet (3.048), 12 feet (3.658M).
(1) It can be used as an instantaneous introduction of a large amount of electrostatic charge due to improper contact with a high static power source. When the ion neutralization cannot be completed, the external air water molecules can be used to provide ion neutralization (for the Corona discharge effect). Effectively eliminate static electricity, and achieve the end goal of static discharge (static voltage balance)
(2) This screw can be used for potential return to zero function (just touch the screw to the ground),
(3) It can be used as a loop detection terminal.
Anti-static silicone wrist strap is the basic of anti-static equipment, and it is also a must-have for the commonly used production line. It is not only very convenient in erection and operation, but also relatively cheap in price. The reason is through the wrist strap and grounding wire. , The static electricity on the human body is discharged to the ground, so the wrist strap must be in contact with the skin when using it, and the grounding wire must also be directly grounded, and ensure that the grounding wire is unimpeded in order to play a greater role.
