Name: Anti-static wrist strap
Product specifications:
Circumference of wrist ring: 20CM, width 1.95CM
Cable length: 1.8M, 2.4M, 3M, any length can also be customized
Connecting wire diameter: 2.05MM, 2.2MM, 2.4MM, 3.0MM
Wrist ring button diameter: 4MM, 7MM, 10MM optional
Connecting cord plug: eight-petal rotatable lantern flower, 4-petal banana head, 4-petal integrated cross flower optional
product material:
The elastic band of the wrist loop is mixed with imported rubber band, high elastic nylon wire and metal conductive wire
The plastic sheet is made of Taihua ABS injection molding, and the rectangular stainless steel sheet is close to the skin.
Black or blue transparent PU material, 7-core copper foil wire wrapped inside
product advantages:
Use a connecting wire to directly connect the human body to the earth to discharge the electrostatic charge accumulated in the human body
The inner surface of the wrist strap has good electrical conductivity, the elastic length can be adjusted arbitrarily, and it is comfortable to wear
The spring cable can withstand more than 20,000 bending tests without breaking
performance:
Resistance at both ends of the ground connection: ≤107Ω
Purification level: Class100
Inner surface resistance: ≤105Ω
Static discharge time: <>
How to use: The human skin must be in close contact with the inner surface of the wristband when in use, and the grounding wire must be connected to the ground through a clamp, grounding terminal or a public grounding socket, and the grounding must be unblocked to exert its effectiveness.
Application: Widely used in electronics factories, IC, semiconductor chips, communications, aerospace, petroleum and other high-tech product manufacturing industries
