Anti-static grounding socket
The anti-static grounding socket is a device in the wrist strap, which is used to connect the earth to release the static electricity accumulated in the human body. When the wrist strap fails, first check the contact of the anti-static grounding socket. In many cases, it is caused by the loosening of the socket due to the movement of people.
The anti-static grounding socket is connected to the wrist strap through the grounding wire. The wrist strap and the skin of the human body are in contact with each other. Static electricity flows from the grounding wire into the grounding socket through contact, completing the hazard avoidance of static electricity risks in production.
Wire material: Yellow-green wire with a wire diameter of 2.5MM, wrapped with multi-core copper wire,
Cable length: 1.8 meters can also be customized according to customer requirements
Plastic sheet, light and durable, can be equipped with one or two 10MM hardware buttons. Different assembly according to usage. The black banana hole holder can also choose one hole, two holes or three holes according to the needs of the wrist strap. The banana socket hole is 4MM, and each connection hole adds a safety grounding resistance.
Just use two screws to fix it directly on the workbench, and the other end of the yellow-green wire is connected to the static grounding branch line through a common terminal or a clamp.
